LVDS DS90CR486VS
Texas Instruments
DS90CR486VS
--
Drivers and Interfaces
LVDS
Specification
| Product Attribute | Attribute Value |
| HTS | 8542.31.00.01 |
| PPAP | No |
| SVHC | Yes |
| EU RoHS | Not Compliant |
| Function | Deserializer |
| Mounting | Surface Mount |
| ECCN (US) | 5A991.b.1 |
| Packaging | Tray |
| Pin Count | 100 |
| Automotive | No |
| Lead Shape | Gull-wing |
| PCB changed | 100 |
| Part Status | Unconfirmed |
| Package Width | 14 |
| Package Height | 1 |
| Package Length | 14 |
| Supplier Package | TQFP |
| Input Signal Type | LVDS |
| Number of Drivers | 48 |
| Number of Receivers | 8 |
| Standard Package Name | QFP |
| SVHC Exceeds Threshold | Yes |
| Maximum Input Current (uA) | 15 |
| Number of Elements per Chip | 8 |
| Transmission Data Rate (MBps) | 6384 |
| Maximum Power Dissipation (mW) | 2900 |
| Maximum Operating Frequency (MHz) | 133 |
| Minimum Operating Frequency (MHz) | 66 |
| Maximum Operating Temperature (°C) | 70 |
| Minimum Operating Temperature (°C) | -10 |
| Maximum Operating Supply Voltage (V) | 3.46 |
| Minimum Operating Supply Voltage (V) | 3.14 |
| Typical Operating Supply Voltage (V) | 3.3 |
| Differential Input Low Threshold Voltage (V) | -0.1 |
| Differential Input High Threshold Voltage (V) | 0.1 |
| Description |
