Instrumentation Amplifiers 5962-87719012A
ADI
5962-87719012A
--
Amplifier
Instrumentation Amplifiers
Specification
| Product Attribute | Attribute Value |
| HTS | 8542.33.00.01 |
| PPAP | No |
| SVHC | Yes |
| EU RoHS | Not Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tube |
| Pin Count | 20 |
| Automotive | No |
| Lead Shape | No Lead |
| PCB changed | 20 |
| Part Status | NRND |
| Package Width | 9.09(Max) |
| Package Height | 2.54(Max) |
| Package Length | 9.09(Max) |
| Supplier Package | CLLCC |
| Minimum CMRR (dB) | 70 |
| Power Supply Type | Dual |
| Standard Package Name | LLCC |
| SVHC Exceeds Threshold | Yes |
| Minimum CMRR Range (dB) | 60 to 75 |
| Supplier Temperature Grade | Military |
| Number of Channels per Chip | 1 |
| Maximum Power Dissipation (mW) | 450 |
| Maximum Dual Supply Voltage (V) | ±18 |
| Maximum Input Resistance (MOhm) | 1000(Typ)@±15V |
| Minimum Dual Supply Voltage (V) | ±6 |
| Typical Dual Supply Voltage (V) | ±9|±12|±15 |
| Maximum Supply Voltage Range (V) | 30 to 50 |
| Maximum Input Offset Voltage (mV) | 0.05(Typ)@±15V |
| Maximum Operating Temperature (°C) | 125 |
| Minimum Operating Temperature (°C) | -55 |
| Maximum Operating Supply Voltage (V) | ±18 |
| Typical Gain Bandwidth Product (MHz) | 25 |
| Description |
