Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| EU RoHS | Compliant |
| Diameter | 5.8 |
| Mounting | Through Hole |
| ECCN (US) | EAR99 |
| Intensity | 1600mW/sr |
| Pin Count | 2 |
| Automotive | No |
| High Power | Yes |
| Lead Shape | Through Hole |
| PCB changed | 2 |
| Part Status | Obsolete |
| LED Material | GaAlAs |
| Package Height | 8.7 |
| High Brightness | Yes |
| Lens Shape Type | Circular |
| Supplier Package | T-1 3/4 |
| Test Current (mA) | 100 |
| Viewing Angle (°) | 20 |
| Reverse Voltage (V) | 5 |
| Lens Dimensions (mm) | 5x5x7.7 |
| Mounting Orientation | Top Mount |
| Peak Wavelength (nm) | 870 |
| Standard Package Name | T-1 3/4 |
| Maximum Forward Voltage (V) | 3@1A |
| Maximum Forward Current (mA) | 100 |
| Maximum Power Dissipation (mW) | 250 |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -25 |
| Description |
