Inductor Surface Mount SRP8540A-5R6M
Bourns
SRP8540A-5R6M
--
Magnetics
Inductor Surface Mount
Specification
| Product Attribute | Attribute Value |
| PPAP | Yes |
| Type | Power |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Tolerance | 20% |
| Automotive | Yes |
| Technology | Wirewound |
| Core Material | Metal Alloy Powder |
| Inductance (H) | 5.6u |
| Protection Style | Shielded |
| Product Depth (mm) | 8.7 |
| Number of Terminals | 2 |
| Product Height (mm) | 4 |
| Product Length (mm) | 9.2 |
| Maximum DC Current (A) | 7.5(Typ) |
| Minimum Quality Factor | 20(Typ) |
| Maximum DC Resistance (Ohm) | 0.035 |
| Inductance Test Frequency (Hz) | 100K |
| Maximum Saturation Current (A) | 17(Typ) |
| Maximum Operating Temperature (°C) | 150 |
| Minimum Operating Temperature (°C) | -55 |
| Minimum Self Resonant Frequency (Hz) | 15M(Typ) |
| Description |
