Inductor Surface Mount SRP6530A-100M
Bourns
SRP6530A-100M
--
Magnetics
Inductor Surface Mount
Specification
| Product Attribute | Attribute Value |
| HTS | 8504.50.80.00 |
| PPAP | Unknown |
| Type | Power |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Tolerance | 20% |
| Automotive | Yes |
| Technology | Wirewound |
| Part Status | Active |
| Core Material | Metal Alloy Powder |
| Inductance (H) | 10u |
| Protection Style | Shielded |
| Product Depth (mm) | 6.9 |
| Number of Terminals | 2 |
| Product Height (mm) | 3 |
| Product Length (mm) | 7.4 |
| Maximum DC Current (A) | 4(Typ) |
| Minimum Quality Factor | 26(Typ) |
| Maximum DC Resistance (Ohm) | 0.105 |
| Quality Test Frequency (Hz) | 2.52M |
| Inductance Test Frequency (Hz) | 500K |
| Maximum Saturation Current (A) | 7(Typ) |
| Maximum Operating Temperature (°C) | 155 |
| Minimum Operating Temperature (°C) | -55 |
| Minimum Self Resonant Frequency (Hz) | 10M(Typ) |
| Inductance Decrease Percentage @ Isat (%) | 30 |
| Description |
