Inductor Surface Mount IHLP5050FDER150M51
Vishay
IHLP5050FDER150M51
--
Magnetics
Inductor Surface Mount
Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| Type | Power Choke |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| Case Size | 5050 |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Tolerance | 20% |
| Automotive | No |
| Technology | Wirewound |
| Part Status | Active |
| Core Material | Powdered Iron |
| Inductance (H) | 15u |
| Protection Style | Shielded |
| Product Depth (mm) | 12.9 |
| Number of Terminals | 2 |
| Product Height (mm) | 6.4 |
| Product Length (mm) | 13.72 |
| Maximum DC Current (A) | 10.1(Typ) |
| Maximum DC Resistance (Ohm) | 0.02568 |
| Inductance Test Frequency (Hz) | 100K |
| Maximum Saturation Current (A) | 7.7(Typ) |
| Maximum Operating Temperature (°C) | 155 |
| Minimum Operating Temperature (°C) | -55 |
| Minimum Self Resonant Frequency (Hz) | 8.8M(Typ) |
| Description |
