Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| Type | RF Choke |
| EU RoHS | Compliant |
| Mounting | Through Hole |
| ECCN (US) | EAR99 |
| Packaging | Tray |
| Tolerance | 10% |
| Automotive | No |
| Lead Style | Radial |
| Technology | Wirewound |
| Part Status | Active |
| Core Material | Ferrite |
| Inductance (H) | 68u |
| Number of Terminals | 2 |
| Product Height (mm) | 10.5 |
| Terminal Pitch (mm) | 6 |
| Product Diameter (mm) | 11 |
| Maximum DC Current (A) | 2.38 |
| Minimum Quality Factor | 6.8 |
| Maximum DC Resistance (Ohm) | 0.11 |
| Quality Test Frequency (Hz) | 2.52M |
| Inductance Test Frequency (Hz) | 100K |
| Maximum Operating Temperature (°C) | 125 |
| Minimum Operating Temperature (°C) | -40 |
| Minimum Self Resonant Frequency (Hz) | 6.8M(Typ) |
| Description |
