Gate and Power Drivers NCP302035MNTWG
onsemi
NCP302035MNTWG
--
Power Management
Gate and Power Drivers
Specification
| Product Attribute | Attribute Value |
| HTS | 8542.39.00.01 |
| PPAP | No |
| Type | MOSFET |
| EU RoHS | Compliant with Exemption |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Pin Count | 31 |
| Automotive | No |
| Driver Type | Low Side|High Side |
| PCB changed | 31 |
| Part Status | Active |
| Package Width | 5 |
| Latch-Up Proof | No |
| Package Height | 0.75(Max) |
| Package Length | 5 |
| Special Features | Under Voltage Lockout |
| Supplier Package | PQFN EP |
| Number of Drivers | 1 |
| Number of Outputs | 1 |
| Maximum Fall Time (ns) | 6(Typ) |
| Maximum Rise Time (ns) | 12(Typ) |
| Peak Output Current (A) | 70 |
| Maximum Supply Current (mA) | 2 |
| High and Low Sides Dependency | Synchronous |
| Maximum Power Dissipation (mW) | 8500 |
| Maximum Operating Frequency (kHz) | 2000 |
| Maximum Operating Temperature (°C) | 125 |
| Maximum Propagation Delay Time (ns) | 52 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Supply Voltage (V) | 5.5 |
| Minimum Operating Supply Voltage (V) | 4.5 |
| Typical Operating Supply Voltage (V) | 5 |
| Typical Input Low Threshold Voltage (V) | 0.7(Max) |
| Typical Input High Threshold Voltage (V) | 2.65(Min) |
| Description |
