Gate and Power Drivers MCP1406-E/AT
Microchip Technology
MCP1406-E/AT
--
Power Management
Gate and Power Drivers
Specification
| Product Attribute | Attribute Value |
| HTS | 8542.39.00.01 |
| Tab | Tab |
| PPAP | Yes |
| Type | IGBT|MOSFET |
| EU RoHS | Compliant |
| Mounting | Through Hole |
| ECCN (US) | EAR99 |
| Packaging | Tube |
| Pin Count | 5 |
| Automotive | Yes |
| Driver Type | Low Side |
| PCB changed | 5 |
| Part Status | Active |
| Package Width | 4.83(Max) |
| Package Height | 9.02(Max) |
| Package Length | 10.67(Max) |
| Supplier Package | TO-220 |
| Number of Drivers | 1 |
| Number of Outputs | 1 |
| Driver Configuration | Inverting |
| Standard Package Name | TO |
| Maximum Fall Time (ns) | 30 |
| Maximum Rise Time (ns) | 30 |
| Output Resistance (Ohm) | 1.5|2.1 |
| Peak Output Current (A) | 6(Typ) |
| Input Logic Compatibility | CMOS|TTL |
| Supplier Temperature Grade | Extended |
| Maximum Supply Current (mA) | 0.25 |
| Maximum Operating Temperature (°C) | 125 |
| Maximum Propagation Delay Time (ns) | 55 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Supply Voltage (V) | 18 |
| Minimum Operating Supply Voltage (V) | 4.5 |
| Typical Input Low Threshold Voltage (V) | 1.3 |
| Typical Input High Threshold Voltage (V) | 1.8 |
| Description |
