Gate and Power Drivers ADUM4137WBRNZ-RL
ADI
ADUM4137WBRNZ-RL
--
Power Management
Gate and Power Drivers
Specification
| Product Attribute | Attribute Value |
| HTS | 8542.39.00.01 |
| PPAP | Unknown |
| Type | MOSFET|IGBT |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Pin Count | 28 |
| Automotive | Yes |
| Bridge Type | Half Bridge |
| Driver Type | Isolated Gate Driver|Low Side|High Side |
| PCB changed | 28 |
| Part Status | Active |
| Package Width | 7.6(Max) |
| Latch-Up Proof | Yes |
| Package Height | 2.4(Max) |
| Package Length | 10.45(Max) |
| Special Features | Under Voltage Lockout |
| Supplier Package | SOIC W |
| Number of Drivers | 1 |
| Number of Outputs | 1 |
| Driver Configuration | Non-Inverting|Inverting |
| Reference Voltage (V) | 9.92(Typ) |
| Peak Output Current (A) | 6(Typ) |
| Input Logic Compatibility | CMOS |
| Supplier Temperature Grade | Automotive |
| Maximum Supply Current (mA) | 6.3(Typ) |
| High and Low Sides Dependency | Synchronous |
| Maximum Power Dissipation (mW) | 2000 |
| Maximum Operating Temperature (°C) | 125 |
| Maximum Propagation Delay Time (ns) | 107(Typ) |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Supply Voltage (V) | 25 |
| Minimum Operating Supply Voltage (V) | 4.5 |
| Typical Input Low Threshold Voltage (V) | 0.9(Max) |
| Typical Input High Threshold Voltage (V) | 2.5(Min) |
| Description |
