5962-0051401Q2A
5962-0051401Q2A
Gate and Power Drivers 5962-0051401Q2A
Texas Instruments
5962-0051401Q2A
--
Power Management
Gate and Power Drivers
Specification
Product AttributeAttribute Value
HTS8542330001
PPAPNo
SVHCYes
EU RoHSNot Compliant
MountingSurface Mount
ECCN (US)EAR99
PackagingTube
Pin Count20
AutomotiveNo
Lead ShapeNo Lead
Driver TypeHigh Speed
PCB changed20
Part StatusActive
Package Width9.09(Max)
Package Height2.03(Max)
Package Length9.09(Max)
Special FeaturesEnable|Thermal Shutdown Protection|Undervoltage Lockout
Supplier PackageCLLCC
Number of Drivers2
Number of Outputs2
Driver ConfigurationNon-Inverting
Standard Package NameLLCC
Maximum Fall Time (ns)50
Maximum Rise Time (ns)50
Peak Output Current (A)3
Input Logic CompatibilityCMOS|TTL
Maximum Supply Current (mA)26
Maximum Operating Temperature (°C)125
Maximum Propagation Delay Time (ns)25
Minimum Operating Temperature (°C)-55
Maximum Operating Supply Voltage (V)35
Minimum Operating Supply Voltage (V)5
Description
Driver 3A 2-OUT High Speed Non-Inv 20-Pin CLLCC Tube
