Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| SVHC | Yes |
| Type | PNP |
| EU RoHS | Compliant with Exemption |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Pin Count | 3 |
| Automotive | No |
| Lead Shape | Gull-wing |
| PCB changed | 3 |
| Part Status | Obsolete |
| Configuration | Single |
| Package Width | 1.6 |
| Package Height | 0.9 |
| Package Length | 2.9 |
| Product Category | Bipolar Power |
| Supplier Package | CPH |
| Standard Package Name | SOT |
| SVHC Exceeds Threshold | Yes |
| Minimum DC Current Gain | 200@100mA@2V |
| Number of Elements per Chip | 1 |
| Maximum Power Dissipation (mW) | 900 |
| Maximum DC Collector Current (A) | 2 |
| Maximum Emitter Base Voltage (V) | 6 |
| Maximum Collector Base Voltage (V) | 30 |
| Maximum Transition Frequency (MHz) | 150(Typ) |
| Maximum Operating Temperature (°C) | 150 |
| Minimum Operating Temperature (°C) | -55 |
| Maximum Collector-Emitter Voltage (V) | 30 |
| Maximum Collector Cut-Off Current (nA) | 100 |
| Maximum Base Emitter Saturation Voltage (V) | 1.2@75mA@1.5A |
| Maximum Collector-Emitter Saturation Voltage (V) | 0.6@75mA@1.5A |
| Description |
