Specification
| Product Attribute | Attribute Value |
| HTS | 8542330001 |
| PPAP | No |
| SVHC | Yes |
| EU RoHS | Not Compliant |
| Bus Hold | No |
| Mounting | Surface Mount |
| Polarity | Inverting/Non-Inverting |
| ECCN (US) | EAR99 |
| Packaging | Rail |
| Pin Count | 14 |
| Set/Reset | Set/Reset |
| Automotive | No |
| Lead Shape | Gull-wing |
| PCB changed | 14 |
| Part Status | Obsolete |
| Logic Family | LS |
| Package Width | 4(Max) |
| Logic Function | D-Type |
| Package Height | 1.5(Max) |
| Package Length | 8.75(Max) |
| Triggering Type | Positive-Edge |
| Supplier Package | SOIC |
| Input Signal Type | Single-Ended |
| Process Technology | Bipolar |
| Standard Package Name | SOP |
| SVHC Exceeds Threshold | Yes |
| Number of Element Inputs | 1 |
| Number of Element Outputs | 1 |
| Number of Channels per Chip | 2 |
| Number of Elements per Chip | 2 |
| Maximum Operating Temperature (°C) | 70 |
| Minimum Operating Temperature (°C) | 0 |
| Absolute Propagation Delay Time (ns) | 40 |
| Maximum Operating Supply Voltage (V) | 5.25 |
| Minimum Operating Supply Voltage (V) | 4.75 |
| Typical Operating Supply Voltage (V) | 5 |
| Maximum Low Level Output Current (mA) | 8 |
| Propagation Delay Test Condition (pF) | 15 |
| Maximum High Level Output Current (mA) | -0.4 |
| Maximum Propagation Delay Time @ Maximum CL (ns) | 40@5V |
| Description |
