Specification
| Product Attribute | Attribute Value |
| HTS | 8542.32.00.71 |
| PPAP | No |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| Cell Type | NOR |
| ECCN (US) | 3A991.b.1.a |
| Packaging | Tray |
| Page Size | 256byte|512byte |
| Pin Count | 24 |
| Automotive | No |
| Boot Block | Yes |
| Lead Shape | Ball |
| ECC Support | Yes |
| PCB changed | 24 |
| Part Status | Active |
| Sector Size | 4Kbyte x 8|224Kbyte x 1|256Kbyte x 511 |
| Timing Type | Synchronous |
| Architecture | Sectored |
| Package Width | 6 |
| Interface Type | Serial (SPI, Dual SPI, Quad SPI) |
| Package Height | 1.2(Max) - 0.2(Min) |
| Package Length | 8 |
| Number of Words | 1G/512M/256M |
| Programmability | Yes |
| Supplier Package | BGA |
| Block Organization | Symmetrical |
| Chip Density (bit) | 1G |
| Command Compatible | Yes |
| Process Technology | 65nm |
| Program Current (mA) | 100 |
| Support of Page Mode | No |
| Max. Access Time (ns) | 8 |
| Standard Package Name | BGA |
| Location of Boot Block | Bottom|Top |
| Maximum Erase Time (S) | 720/Chip |
| Operating Current (mA) | 100 |
| Address Bus Width (bit) | 32 |
| Programming Voltage (V) | 1.7 to 2 |
| Number of Bits/Word (bit) | 1/2/4 |
| Minimum Endurance (Cycles) | 100000 |
| Supplier Temperature Grade | Industrial |
| Maximum Programming Time (ms) | 2/Page |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Supply Voltage (V) | 2 |
| Minimum Operating Supply Voltage (V) | 1.7 |
| Typical Operating Supply Voltage (V) | 1.8 |
| Description |
