Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| Cell Type | NOR |
| ECCN (US) | 3A991.B.1.A |
| Packaging | Tray |
| Page Size | 8Words/16byte |
| Pin Count | 64 |
| Automotive | No |
| Boot Block | No |
| Lead Shape | Ball |
| ECC Support | No |
| PCB changed | 64 |
| Part Status | Obsolete |
| Sector Size | 64Kbyte x 128 |
| Timing Type | Asynchronous |
| Architecture | Sectored |
| Package Width | 9 |
| Interface Type | Parallel |
| Package Height | 0.6(Min) |
| Package Length | 9 |
| Number of Words | 8M/4M |
| Programmability | Yes |
| Supplier Package | Fortified BGA |
| Block Organization | Symmetrical |
| Chip Density (bit) | 64M |
| Command Compatible | Yes |
| Process Technology | 110nm, MirrorBit |
| OE Access Time (ns) | 25 |
| Program Current (mA) | 60 |
| Support of Page Mode | Yes |
| Max. Access Time (ns) | 90 |
| Standard Package Name | BGA |
| Maximum Erase Time (S) | 128/Chip |
| Operating Current (mA) | 50 |
| Page Read Current (mA) | 20 |
| Address Bus Width (bit) | 23/22 |
| Programming Voltage (V) | 2.7 to 3.6 |
| Number of Bits/Word (bit) | 8/16 |
| Minimum Endurance (Cycles) | 100000 |
| Supplier Temperature Grade | Industrial |
| Maximum Page Access Time (ns) | 25 |
| Maximum Programming Time (ms) | 63000(Typ)/Chip |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Supply Voltage (V) | 3.6 |
| Minimum Operating Supply Voltage (V) | 2.7 |
| Typical Operating Supply Voltage (V) | 3.3|3 |
| Description |
