Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| Cell Type | NOR |
| ECCN (US) | 3A991.b.1.a |
| Page Size | 16Words |
| Pin Count | 64 |
| Automotive | No |
| Boot Block | No |
| ECC Support | No |
| PCB changed | 64 |
| Part Status | Obsolete |
| Sector Size | 128Kbyte x 256 |
| Timing Type | Asynchronous |
| Architecture | Sectored |
| Package Width | 10 |
| Interface Type | Parallel |
| Package Height | 0.78 |
| Package Length | 13 |
| Number of Words | 32M/16M |
| Programmability | Yes |
| Supplier Package | EZBGA |
| Block Organization | Symmetrical |
| Chip Density (bit) | 256M |
| Command Compatible | No |
| OE Access Time (ns) | 25 |
| Program Current (mA) | 50 |
| Support of Page Mode | Yes |
| Max. Access Time (ns) | 95 |
| Standard Package Name | BGA |
| Maximum Erase Time (s) | 4/Main Block |
| Operating Current (mA) | 31 |
| Page Read Current (mA) | 16 |
| Address Bus Width (bit) | 25/24 |
| Programming Voltage (V) | 2.7 to 3.6 |
| Number of Bits/Word (bit) | 8/16 |
| Maximum Page Access Time (ns) | 25 |
| Maximum Programming Time (ms) | 0.456/Word |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Supply Voltage (V) | 3.6 |
| Minimum Operating Supply Voltage (V) | 2.7 |
| Typical Operating Supply Voltage (V) | 3|3.3 |
| Description |
