Specification
| Product Attribute | Attribute Value |
| HTS | 8542.32.00.71 |
| PPAP | No |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| Cell Type | NOR |
| ECCN (US) | 3A991.b.1.a |
| Packaging | Tray |
| Page Size | 4Words |
| Pin Count | 64 |
| Automotive | No |
| Boot Block | Yes |
| ECC Support | No |
| PCB changed | 64 |
| Part Status | Obsolete |
| Sector Size | 32Kbyte x 4|128Kbyte x 127 |
| Timing Type | Asynchronous|Synchronous |
| Architecture | Sectored |
| Package Width | 8 |
| Interface Type | Serial|Parallel |
| Package Height | 0.78 |
| Package Length | 10 |
| Number of Words | 8M |
| Programmability | Yes |
| Supplier Package | EZBGA |
| Block Organization | Asymmetrical |
| Chip Density (bit) | 128M |
| Command Compatible | No |
| OE Access Time (ns) | 25 |
| Program Current (mA) | 51 |
| Support of Page Mode | Yes |
| Max. Access Time (ns) | 85 |
| Standard Package Name | BGA |
| Location of Boot Block | Bottom |
| Maximum Erase Time (s) | 4/Main Block |
| Operating Current (mA) | 28 |
| Page Read Current (mA) | 12 |
| Address Bus Width (bit) | 23 |
| Programming Voltage (V) | 8.5 to 9.5|1.5 to 3.6 |
| Number of Bits/Word (bit) | 16 |
| Maximum Page Access Time (ns) | 25 |
| Maximum Programming Time (ms) | 0.2/Word |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Supply Voltage (V) | 3.6 |
| Minimum Operating Supply Voltage (V) | 2.3 |
| Typical Operating Supply Voltage (V) | 2.5|3.3 |
| Description |
