Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| EU RoHS | Supplier Unconfirmed |
| Mounting | Surface Mount |
| Cell Type | NOR |
| ECCN (US) | 3A991.b.1.a |
| Pin Count | 80 |
| Automotive | No |
| Boot Block | Yes |
| Lead Shape | Gull-wing |
| ECC Support | No |
| PCB changed | 80 |
| Part Status | Obsolete |
| Sector Size | 8Kbyte x 8|16Kbyte x 4|64Kbyte x 62 |
| Timing Type | Asynchronous|Synchronous |
| Architecture | Sectored |
| Package Width | 14 |
| Interface Type | Parallel|Serial |
| Package Height | 2.8 |
| Package Length | 20 |
| Number of Words | 1M |
| Programmability | Yes |
| Supplier Package | PQFP |
| Block Organization | Asymmetrical |
| Chip Density (bit) | 32M |
| Command Compatible | No |
| Program Current (mA) | 30 |
| Support of Page Mode | Yes |
| Max. Access Time (ns) | 45 |
| Standard Package Name | QFP |
| Location of Boot Block | Bottom |
| Maximum Erase Time (S) | 2/Block |
| Operating Current (mA) | 50 |
| Address Bus Width (bit) | 20 |
| Number of Bits/Word (bit) | 32 |
| Supplier Temperature Grade | Industrial |
| Maximum Page Access Time (ns) | 25 |
| Maximum Programming Time (ms) | 20000/Chip |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Supply Voltage (V) | 3.6 |
| Minimum Operating Supply Voltage (V) | 3 |
| Typical Operating Supply Voltage (V) | 3.3 |
| Description |
