Digital to Analog Converters - DACs AD7542BQ
ADI
AD7542BQ
--
Data Acquisition
Digital to Analog Converters - DACs
Specification
| Product Attribute | Attribute Value |
| HTS | 8542.39.00.01 |
| PPAP | No |
| SVHC | Yes |
| EU RoHS | Not Compliant |
| Mounting | Through Hole |
| ECCN (US) | EAR99 |
| Packaging | Tube |
| Pin Count | 16 |
| Automotive | No |
| Lead Shape | Through Hole |
| Resolution | 12bit |
| Output Type | Current |
| PCB changed | 16 |
| Part Status | NRND |
| Architecture | R-2R|Current Steering |
| Package Width | 7.87(Max) |
| Converter Type | General Purpose |
| Package Height | 3.56(Max) |
| Package Length | 21.34(Max) |
| Full Scale Error | ±4LSB |
| Supplier Package | CDIP |
| Power Supply Type | Single |
| Voltage Reference | External |
| Process Technology | CMOS |
| Standard Package Name | DIP |
| Digital Interface Type | Parallel |
| Digital Supply Support | No |
| Number of DAC Channels | 1 |
| SVHC Exceeds Threshold | Yes |
| Maximum Settling Time (us) | 2(Typ) |
| Number of Outputs per Chip | 1 |
| Supplier Temperature Grade | Industrial |
| Integral Nonlinearity Error | ±0.5LSB |
| Maximum Power Dissipation (mW) | 450 |
| Maximum Single Supply Voltage (V) | 5.25 |
| Minimum Single Supply Voltage (V) | 4.75 |
| Typical Single Supply Voltage (V) | 5 |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Description |
