DC to DC Converter and Switching Regulator Module UWS-5/10-Q12P-C
Murata
UWS-5/10-Q12P-C
--
Power Supplies
DC to DC Converter and Switching Regulator Module
Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| Type | Step Down |
| EU RoHS | Compliant with Exemption |
| Mounting | Through Hole |
| ECCN (US) | EAR99 |
| Isolation | Isolated |
| Packaging | Tray |
| Pin Count | 8 |
| Automotive | No |
| Output Type | Fixed |
| PCB changed | 8 |
| Part Status | Active |
| On/Off Logic | Positive |
| Package Width | 33 |
| Efficiency (%) | 91(Typ) |
| Package Height | 9.1 - 0.25(Min) |
| Package Length | 22.9 |
| Line Regulation | 0.125% |
| Load Regulation | 0.125% |
| Output Power (W) | 50 |
| Supplier Package | 1/16-Brick |
| Input/Output Type | DC/DC |
| Number of Outputs | 1 |
| Output Current (A) | 10 |
| Output Voltage (V) | 5 |
| Product Weight (g) | 13.6 |
| Switching Regulator | Yes |
| Maximum Input Voltage (V) | 36 |
| Minimum Input Voltage (V) | 9 |
| Minimum Isolation Voltage | 2250VDC |
| Switching Frequency (kHz) | 325 |
| Typical Input Voltage (V) | 24 |
| Typical Standby Current (mA) | 1 |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Description |
