DC to DC Converter and Switching Regulator Module PWR1546AC
Murata
PWR1546AC
--
Power Supplies
DC to DC Converter and Switching Regulator Module
Specification
| Product Attribute | Attribute Value |
| HTS | 8542.39.00.01 |
| PPAP | No |
| Type | Step Up |
| EU RoHS | Compliant with Exemption |
| Mounting | Through Hole |
| ECCN (US) | EAR99 |
| Isolation | Isolated |
| Pin Count | 5 |
| Automotive | No |
| Output Type | Fixed |
| PCB changed | 5 |
| Part Status | Active |
| Package Width | 50.8 |
| Efficiency (%) | 60(Typ) |
| Package Height | 10.16 |
| Package Length | 50.8 |
| Line Regulation | 0.02%(Typ) |
| Load Regulation | 0.1%(Typ) |
| Output Power (W) | 5 |
| Input/Output Type | DC/DC |
| Number of Outputs | 2 |
| Output Current (A) | 0.167|-0.167 |
| Output Voltage (V) | 15|-15 |
| Product Weight (g) | 50 |
| Switching Regulator | Yes |
| Minimum Isolation Voltage | 750VDC |
| Switching Frequency (kHz) | 50(Typ) |
| Typical Input Voltage (V) | 5 |
| Maximum Operating Temperature (°C) | 100 |
| Minimum Operating Temperature (°C) | -40 |
| Description |
