DC to DC Converter and Switching Regulator Module BWR-5/700-D48A-C
Murata
BWR-5/700-D48A-C
--
Power Supplies
DC to DC Converter and Switching Regulator Module
Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| Type | Non-Inverting|Inverting|Step Down |
| EU RoHS | Compliant with Exemption |
| Mounting | Through Hole |
| ECCN (US) | EAR99 |
| Isolation | Isolated |
| Pin Count | 5 |
| Automotive | No |
| Output Type | Fixed |
| PCB changed | 5 |
| Part Status | NRND |
| Package Width | 25.4 |
| Efficiency (%) | 81(Typ) |
| Package Height | 9.53 |
| Package Length | 50.8 |
| Line Regulation | 0.3% |
| Load Regulation | 1% |
| Output Power (W) | 10 |
| Supplier Package | Case C-2 |
| Input/Output Type | DC/DC |
| Number of Outputs | 2 |
| Output Current (A) | 0.7|-0.7 |
| Output Voltage (V) | 5|-5 |
| Product Weight (g) | 37 |
| Switching Regulator | Yes |
| Standard Package Name | Case C-2 |
| Maximum Input Voltage (V) | 75 |
| Minimum Input Voltage (V) | 18 |
| Minimum Isolation Voltage | 1500VDC |
| Switching Frequency (kHz) | 150 to 180 |
| Typical Input Voltage (V) | 48 |
| Maximum Operating Temperature (°C) | 100 |
| Minimum Operating Temperature (°C) | -40 |
| Description |
