DC to DC Converter and Switching Regulator Chip TPS62180YZFT
Texas Instruments
TPS62180YZFT
--
Power Management
DC to DC Converter and Switching Regulator Chip
Specification
| Product Attribute | Attribute Value |
| HTS | 8542330001 |
| PPAP | No |
| SVHC | Yes |
| Type | Synchronous Step Down |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Pin Count | 24 |
| Automotive | No |
| Lead Shape | Ball |
| Output Type | Adjustable |
| PCB changed | 24 |
| Part Status | Active |
| Package Width | 2.13(Max) |
| Package Height | 0.28(Max) |
| Package Length | 3.13(Max) |
| Line Regulation | 0.01%/V |
| Load Regulation | 0.04%/A |
| Supplier Package | DSBGA |
| Number of Outputs | 1 |
| Output Voltage (V) | 0.9 to 6 |
| Switching Regulator | No |
| Standard Package Name | BGA |
| Maximum Input Voltage (V) | 15 |
| Minimum Input Voltage (V) | 4 |
| Maximum Output Current (A) | 6(Typ) |
| Typical Switch Current (A) | 4.7 |
| Operating Supply Voltage (V) | 4 to 15 |
| Typical Quiescent Current (uA) | 28 |
| Typical Output Resistance (Ohm) | 60 |
| Maximum Operating Temperature (°C) | 125 |
| Minimum Operating Temperature (°C) | -40 |
| Description |
