DC to DC Converter and Switching Regulator Chip ADP5073ACPZ-R7
ADI
ADP5073ACPZ-R7
--
Power Management
DC to DC Converter and Switching Regulator Chip
Specification
| Product Attribute | Attribute Value |
| HTS | 8542330001 |
| PPAP | No |
| Type | Synchronous Inverting |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Pin Count | 16 |
| Automotive | No |
| Lead Shape | No Lead |
| Output Type | Adjustable |
| PCB changed | 16 |
| Part Status | Active |
| Package Width | 3 |
| Package Height | 0.73 |
| Package Length | 3 |
| Line Regulation | 0.02%/V(Typ) |
| Load Regulation | 0.0025%/A(Typ) |
| Supplier Package | LFCSP EP |
| Number of Outputs | 1 |
| Output Voltage (V) | -0.5 to -36.15 |
| Switching Regulator | Yes |
| Standard Package Name | CSP |
| Maximum Input Voltage (V) | 15 |
| Minimum Input Voltage (V) | 2.85 |
| Switching Frequency (kHz) | 2400(Typ) |
| Typical Switch Current (A) | 1.375 |
| Operating Supply Voltage (V) | 2.85 to 15 |
| Typical Quiescent Current (uA) | 1800 |
| Maximum Operating Temperature (°C) | 125 |
| Minimum Operating Temperature (°C) | -40 |
| Description |
