DC to DC Converter and Switching Regulator Chip ADP2230ACPZ-R7
ADI
ADP2230ACPZ-R7
--
Power Management
DC to DC Converter and Switching Regulator Chip
Specification
| Product Attribute | Attribute Value |
| HTS | 8542.39.00.01 |
| PPAP | No |
| Type | Synchronous Step Down |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Pin Count | 10 |
| Automotive | No |
| Lead Shape | No Lead |
| Output Type | Adjustable |
| PCB changed | 10 |
| Part Status | Active |
| Package Width | 3 |
| Efficiency (%) | 94 |
| Package Height | 0.73 |
| Package Length | 3 |
| Line Regulation | 0.1%/V(Typ) |
| Load Regulation | 0.1%/A(Typ) |
| Supplier Package | LFCSP EP |
| Number of Outputs | 2 |
| Output Voltage (V) | 0.8 to 6 |
| Switching Regulator | Yes |
| Standard Package Name | CSP |
| Maximum Input Voltage (V) | 6.5 |
| Minimum Input Voltage (V) | 2.3 |
| Switching Frequency (kHz) | 2000(Typ) |
| Maximum Output Current (A) | 0.8(Min) |
| Typical Switch Current (A) | 1.3 |
| Operating Supply Voltage (V) | 2.3 to 6.5 |
| Typical Quiescent Current (uA) | 55 |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Description |
