LTC3864EMSE#PBF
LTC3864EMSE#PBF
DC to DC Controllers LTC3864EMSE#PBF
ADI
LTC3864EMSE#PBF
--
Processors&Controllers
DC to DC Controllers
Specification
Product AttributeAttribute Value
HTS8542330001
PPAPNo
EU RoHSCompliant
MountingSurface Mount
TopologyStep Down
ECCN (US)EAR99
PackagingTube
Pin Count12
AutomotiveNo
Lead ShapeGull-wing
PCB changed12
Part StatusActive
Package Width3
Package Height0.86
Package Length4.04
Supplier PackageMSOP EP
Number of Outputs1
Output Voltage (V)0.8 to 60
Standard Package NameSOP
Maximum Input Voltage (V)60
Minimum Input Voltage (V)3.5
Supplier Temperature GradeExtended
Maximum Supply Current (mA)0.04
Operating Supply Voltage (V)3.5 to 60
Typical Quiescent Current (mA)0.04
Maximum Switching Frequency (kHz)850
Minimum Switching Frequency (kHz)50
Maximum Operating Temperature (°C)125
Minimum Operating Temperature (°C)-40
Typical Gate Driver Pull Up Resistance (Ohm)2
Typical Gate Driver Pull Down Resistance (Ohm)0.9
Description
DC/DC Cntrlr Single-OUT Step Down 850kHz Automotive 12-Pin MSOP EP Tube
