Current Mode PWM Controllers UCC3809N-1G4
Texas Instruments
UCC3809N-1G4
--
Power Management
Current Mode PWM Controllers
Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| Type | Primary Side PWM Controller |
| EU RoHS | Compliant |
| Mounting | Through Hole |
| ECCN (US) | EAR99 |
| Pin Count | 8 |
| Automotive | No |
| Lead Shape | Through Hole |
| PCB changed | 8 |
| Part Status | Obsolete |
| Package Width | 6.6(Max) |
| Package Height | 5.08(Max) - 0.51(Min) |
| Package Length | 10.16(Max) |
| Supplier Package | PDIP |
| Output Current (mA) | 0.8 |
| Number of PWM Outputs | 1 |
| Standard Package Name | DIP |
| Maximum Duty Cycle (%) | 70(Typ) |
| Switching Frequency (kHz) | 1000 |
| Maximum Operating Temperature (°C) | 70 |
| Minimum Operating Temperature (°C) | 0 |
| Description |
