Current Mode PWM Controllers LM5046SQ/NOPB
Texas Instruments
LM5046SQ/NOPB
--
Power Management
Current Mode PWM Controllers
Specification
| Product Attribute | Attribute Value |
| HTS | 8542330001 |
| PPAP | No |
| SVHC | Yes |
| Type | Current Mode PWM Controller |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| Topology | Full-Bridge|Boost |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Pin Count | 28 |
| Automotive | No |
| Lead Shape | No Lead |
| On/Off Pin | No |
| PCB changed | 28 |
| Part Status | Active |
| Package Width | 5.1(Max) |
| Control Method | Current/Voltage Mode PWM Controller |
| Fall Time (ns) | 20 |
| Package Height | 0.75(Max) |
| Package Length | 5.1(Max) |
| Rise Time (ns) | 60 |
| Synchronous Pin | Yes |
| Supplier Package | WQFN EP |
| Adjustable Output | No |
| Output Current (mA) | 2000 |
| Number of PWM Outputs | 2 |
| Standard Package Name | QFN |
| Maximum Duty Cycle (%) | 0(Min) |
| Switching Frequency (kHz) | 100 to 2000 |
| Maximum Supply Current (mA) | 4.6(Typ) |
| Maximum Operating Temperature (°C) | 125 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Supply Voltage (V) | 14 |
| Minimum Operating Supply Voltage (V) | 10 |
