Counter Shift Registers 74HC4059D,118
NXP
74HC4059D,118
--
Standard and Specialty Logic
Counter Shift Registers
Specification
| Product Attribute | Attribute Value |
| HTS | 8542330001 |
| PPAP | No |
| Type | Decade |
| EU RoHS | Supplier Unconfirmed |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Pin Count | 24 |
| Automotive | No |
| PCB changed | 24 |
| Part Status | Obsolete |
| Logic Family | HC |
| Package Width | 7.6(Max) |
| Direction Type | Uni-Directional |
| Logic Function | Counter/Divider |
| Operation Mode | Down Counter |
| Package Height | 2.45(Max) |
| Package Length | 15.6(Max) |
| Triggering Type | Positive-Edge |
| Number of Stages | 5 |
| Supplier Package | SO |
| Process Technology | CMOS |
| Parallel Enable Input | No |
| Terminal Count Output | No |
| Number of Element Inputs | 1 |
| Number of Element Outputs | 1 |
| Number of Elements per Chip | 1 |
| Number of Count Input Enables | 0 |
| Maximum Quiescent Current (mA) | 0.008 |
| Maximum Operating Temperature (°C) | 125 |
| Minimum Operating Temperature (°C) | -40 |
| Absolute Propagation Delay Time (ns) | 300 |
| Maximum Operating Supply Voltage (V) | 6 |
| Minimum Operating Supply Voltage (V) | 2 |
| Typical Operating Supply Voltage (V) | 5 |
| Propagation Delay Test Condition (pF) | 50 |
| Number of Selection Inputs per Element | 3 |
| Maximum Propagation Delay Time @ Maximum CL (ns) | 34@6V|200@2V|40@4.5V |
| Description |
