Controlled Oscillators HMC1164LP5E
ADI
HMC1164LP5E
--
Oscillators and Crystals
Controlled Oscillators
Specification
| Product Attribute | Attribute Value |
| HTS | 8542330001 |
| PPAP | No |
| Type | Voltage Controlled Oscillator (VCO) |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Pin Count | 32 |
| Automotive | No |
| Lead Shape | No Lead |
| PCB changed | 32 |
| Part Status | Active |
| Package Width | 5 |
| Package Height | 0.88 |
| Package Length | 5 |
| Supplier Package | LFCSP EP |
| Tuning Voltage (V) | 2 to 13 |
| Frequency Range (MHz) | 10380 to 11300|5190 to 5650 |
| Lower Frequency (MHz) | 10380|5190 |
| Standard Package Name | CSP |
| Upper Frequency (MHz) | 11300|5650 |
| Output Frequency (MHz) | 10380 to 11300|5190 to 5650 |
| Maximum Supply Current (mA) | 290 |
| Typical Phase Noise (dBc/Hz) | -114@100KHz |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Supply Voltage (V) | 5.5 |
| Typical Operating Supply Voltage (V) | 5 |
| Description |
