Comparators TL331BQDBVRQ1
Texas Instruments
TL331BQDBVRQ1
--
Amplifier
Comparators
Specification
| Product Attribute | Attribute Value |
| PPAP | Yes |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Pin Count | 5 |
| Automotive | Yes |
| Output Type | Open Collector |
| PCB changed | 5 |
| Part Status | Active |
| Rail to Rail | Rail to Rail Output |
| Package Width | 1.75(Max) |
| Package Height | 1.1 |
| Package Length | 3.05(Max) |
| Supplier Package | SOT-23 |
| Manufacturer Type | General Purpose Comparator |
| Power Supply Type | Dual|Single |
| Typical Voltage Gain (dB) | 106.02 |
| Supplier Temperature Grade | Automotive |
| Typical Response Time (us) | 1 |
| Number of Channels per Chip | 1 |
| Typical Output Current (mA) | 20(Max) |
| Maximum Quiescent Current (mA) | 0.33@5V |
| Maximum Dual Supply Voltage (V) | ±18 |
| Maximum Input Bias Current (uA) | 0.025@5V |
| Minimum Dual Supply Voltage (V) | ±1 |
| Typical Dual Supply Voltage (V) | ±15|±12|±9|±5|±3 |
| Typical Voltage Gain Range (dB) | 90 to 110 |
| Typical Response Time Range (us) | 0.5 to 5 |
| Maximum Input Offset Voltage (mV) | 2.5@36V |
| Maximum Single Supply Voltage (V) | 36 |
| Minimum Single Supply Voltage (V) | 2 |
| Typical Single Supply Voltage (V) | 3|5|9|28|24|18|15|12 |
| Maximum Operating Temperature (°C) | 125 |
| Maximum Propagation Delay Time (ns) | 1000(Typ) |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Supply Voltage (V) | 36|±18 |
| Description |
