Capacitor Aluminum ALA7DA301CF550
KEMET
ALA7DA301CF550
--
Capacitors
Capacitor Aluminum
Specification
| Product Attribute | Attribute Value |
| PPAP | Yes |
| Type | Electrolytic |
| EU RoHS | Compliant |
| IL (uA) | 990@5Min |
| IR (mA) | 2000 |
| Voltage | 550VDC |
| Mounting | Through Hole |
| Polarity | Polar |
| ESR (Ohm) | 0.567 |
| Size (mm) | 30 X 50 |
| Tolerance | 20% |
| Automotive | Yes |
| Part Status | Active |
| Construction | Aluminum Cylindrical Can |
| Lifetime (H) | 13000 |
| Special Features | Long Life|Compact Size|High Voltage|Excellent Surge Voltage Capability|High Ripple Current |
| Capacitance Value | 300uF |
| Termination Style | Snap-In |
| Product Weight (g) | 60 |
| Number of Terminals | 2 |
| Product Height (mm) | 50 |
| Terminal Pitch (mm) | 10 |
| Height Tolerance (mm) | ±2 |
| Product Diameter (mm) | 30 |
| Diameter Tolerance (mm) | 1 |
| Maximum Impedance (Ohm) | 0.392@20°C@10kHz |
| Equivalent Series Resistance Type | Low |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Description |
