Product Attribute | Attribute Value |
PPAP | No |
Type | Rotary |
EU RoHS | Compliant |
Mounting | Surface Mount |
Linearity | Yes |
Packaging | Tape and Reel |
Pin Count | 4 |
Automotive | No |
Resolution | Infinite |
PCB changed | 4 |
Part Status | Obsolete |
Package Width | 12.65 |
Package Height | 2.2 |
Package Length | 10.6 |
Power Rating (W) | 0.05@50°C |
Supplier Package | SMD |
Mechanical Travel | 360° |
Resistance (kohm) | 10 |
Linearity Error (%) | ±2.5 |
Standard Package Name | SMD |
Resistance Tolerance (%) | ±30 |
Maximum Operating Torque (N.m) | 0.00003 |
Maximum Operating Temperature (°C) | 85 |
Minimum Operating Temperature (°C) | -40 |
Maximum Operating Supply Voltage (V) | 5 |
Description |
