Angular and Linear Position Sensors 3382G-1-503G
Bourns
3382G-1-503G
--
Sensor
Angular and Linear Position Sensors
Specification
| Product Attribute | Attribute Value |
| PPAP | Yes |
| Type | Rotary |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| Topology | v(1,1) |
| Linearity | Yes |
| Packaging | Tape and Reel |
| Pin Count | 3 |
| Automotive | Yes |
| Resolution | Infinite |
| Output Type | Analog(Voltage) |
| PCB changed | 3 |
| Part Status | Active |
| Package Width | 12.04 |
| Package Height | 3.23 |
| Package Length | 11 |
| Power Rating (W) | 0.05@50°C |
| Shock Rating (g) | 20 |
| Supplier Package | SMD |
| Mechanical Travel | 360° |
| Resistance (kOhm) | 50 |
| Dielectric Strength | 500VAC |
| Linearity Error (%) | ±2 |
| Shaft Diameter (mm) | 4 |
| Standard Package Name | SMD |
| Operating Life (Cycles) | 1M |
| Resistance Tolerance (%) | ±30 |
| Maximum Operating Torque (N.m) | 0.003 |
| Temperature Coefficient (ppm/°C) | ±500 |
| Maximum Operating Temperature (°C) | 120 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Supply Voltage (V) | 16 |
| Description |
