Analog to Digital Converters - ADCs LTC1091ACN8#PBF
ADI
LTC1091ACN8#PBF
--
Data Acquisition
Analog to Digital Converters - ADCs
Specification
| Product Attribute | Attribute Value |
| HTS | 8542.39.00.01 |
| PPAP | No |
| EU RoHS | Compliant |
| Mounting | Through Hole |
| ECCN (US) | EAR99 |
| Packaging | Tube |
| Pin Count | 8 |
| Automotive | No |
| Input Type | Voltage |
| Lead Shape | Through Hole |
| Resolution | 10bit |
| PCB changed | 8 |
| Part Status | Active |
| Architecture | SAR |
| Input Voltage | 5V |
| Package Width | 6.48 |
| Sampling Rate | 31ksps |
| Converter Type | General Purpose |
| Number of ADCs | 1 |
| Package Height | 3.3 |
| Package Length | 10.16(Max) |
| Sample and Hold | Yes |
| Full Scale Error | ±1LSB |
| Supplier Package | PDIP N |
| Input Signal Type | Single-Ended|Differential |
| Voltage Reference | Supply |
| Single-Ended Input | Yes |
| Standard Package Name | DIP |
| Voltage Supply Source | Single |
| Digital Interface Type | Serial (4-Wire, SPI, Microwire) |
| Digital Supply Support | No |
| Number of Input Channels | 2|1 |
| Polarity of Input Voltage | Unipolar |
| Supplier Temperature Grade | Commercial |
| Integral Nonlinearity Error | ±0.5LSB |
| Maximum Power Dissipation (mW) | 500 |
| Maximum Single Supply Voltage (V) | 10 |
| Minimum Single Supply Voltage (V) | 4.5 |
| Typical Single Supply Voltage (V) | 5 |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Description |
