Analog to Digital Converters - ADCs ADS804EG4
Texas Instruments
ADS804EG4
--
Data Acquisition
Analog to Digital Converters - ADCs
Specification
| Product Attribute | Attribute Value |
| HTS | 8542330001 |
| PPAP | No |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| ECCN (US) | 3A991c.2. |
| Packaging | Tube |
| Pin Count | 28 |
| Automotive | No |
| Input Type | Voltage |
| Lead Shape | Gull-wing |
| Resolution | 12bit |
| PCB changed | 28 |
| Part Status | Unconfirmed |
| Architecture | Pipelined |
| Input Voltage | 3.5V/5V |
| Package Width | 5.6(Max) |
| Sampling Rate | 10Msps |
| Converter Type | General Purpose |
| Number of ADCs | 1 |
| Package Height | 2(Max) - 0.05(Min) |
| Package Length | 10.5(Max) |
| Sample and Hold | Yes |
| Full Scale Error | ±2%FSR |
| Supplier Package | SSOP |
| Input Signal Type | Single-Ended|Differential |
| Voltage Reference | Internal|External |
| Single-Ended Input | Yes |
| Signal to Noise Ratio | 69dBFS(Typ) |
| Standard Package Name | SOP |
| Voltage Supply Source | Single |
| Digital Interface Type | Parallel |
| Digital Supply Support | No |
| No Missing Codes (bit) | 12 |
| Number of Input Channels | 1 |
| Polarity of Input Voltage | Unipolar |
| Integral Nonlinearity Error | ±2LSB |
| Maximum Power Dissipation (mW) | 200 |
| Typical Power Dissipation (mW) | 180 |
| Maximum Single Supply Voltage (V) | 5.3 |
| Minimum Single Supply Voltage (V) | 4.7 |
| Typical Single Supply Voltage (V) | 5 |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Description |
