Analog to Digital Converters - ADCs ADC0804LCWM/NOPB
Texas Instruments
ADC0804LCWM/NOPB
--
Data Acquisition
Analog to Digital Converters - ADCs
Specification
| Product Attribute | Attribute Value |
| HTS | 8542330001 |
| PPAP | No |
| SVHC | Yes |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tube |
| Pin Count | 20 |
| Automotive | No |
| Input Type | Voltage |
| Lead Shape | Gull-wing |
| Resolution | 8bit |
| PCB changed | 20 |
| Part Status | Active |
| Architecture | SAR |
| Input Voltage | 5V |
| Package Width | 7.6(Max) |
| Sampling Rate | 10ksps |
| Converter Type | General Purpose |
| Number of ADCs | 1 |
| Package Height | 2.35(Max) |
| Package Length | 13(Max) |
| Sample and Hold | No |
| Supplier Package | SOIC |
| Input Signal Type | Differential |
| Voltage Reference | Supply|External |
| Single-Ended Input | No |
| Standard Package Name | SOP |
| Voltage Supply Source | Single |
| Digital Interface Type | Parallel |
| Digital Supply Support | No |
| Number of Input Channels | 1 |
| Polarity of Input Voltage | Unipolar |
| Integral Nonlinearity Error | ±1LSB |
| Maximum Power Dissipation (mW) | 875 |
| Maximum Single Supply Voltage (V) | 6.3 |
| Minimum Single Supply Voltage (V) | 4.5 |
| Typical Single Supply Voltage (V) | 5 |
| Maximum Operating Temperature (°C) | 70 |
| Minimum Operating Temperature (°C) | 0 |
| Description |
