Analog to Digital Converters - ADCs AD9238BCPZRL-65
ADI
AD9238BCPZRL-65
--
Data Acquisition
Analog to Digital Converters - ADCs
Specification
| Product Attribute | Attribute Value |
| HTS | 8542.39.00.01 |
| PPAP | No |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Pin Count | 64 |
| Automotive | No |
| Input Type | Voltage |
| Lead Shape | No Lead |
| Resolution | 12bit |
| PCB changed | 64 |
| Part Status | Active |
| Architecture | Pipelined |
| Input Voltage | 1Vp-p/2Vp-p |
| Package Width | 9 |
| Sampling Rate | 65Msps |
| Converter Type | General Purpose |
| Number of ADCs | 2 |
| Package Height | 0.83 |
| Package Length | 9 |
| Sample and Hold | Yes |
| Full Scale Error | ±2.5%FSR |
| Supplier Package | LFCSP EP |
| Input Signal Type | Single-Ended|Differential |
| Voltage Reference | Internal|External |
| Single-Ended Input | Yes |
| Signal to Noise Ratio | 70.3dB(Typ) |
| Standard Package Name | CSP |
| Voltage Supply Source | Single |
| Digital Interface Type | Parallel |
| Digital Supply Support | No |
| No Missing Codes (bit) | 12 |
| Number of Input Channels | 2 |
| Polarity of Input Voltage | Unipolar |
| Supplier Temperature Grade | Industrial |
| Integral Nonlinearity Error | ±1.75LSB |
| Maximum Power Dissipation (mW) | 698 |
| Typical Power Dissipation (mW) | 640 |
| Maximum Single Supply Voltage (V) | 3.6 |
| Minimum Single Supply Voltage (V) | 2.7 |
| Typical Single Supply Voltage (V) | 3 |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Description |
