Analog to Digital Converters - ADCs AD7890ARZ-4
ADI
AD7890ARZ-4
--
Data Acquisition
Analog to Digital Converters - ADCs
Specification
| Product Attribute | Attribute Value |
| HTS | 8542.39.00.01 |
| PPAP | No |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tube |
| Pin Count | 24 |
| Automotive | No |
| Input Type | Voltage |
| Lead Shape | Gull-wing |
| Resolution | 12bit |
| PCB changed | 24 |
| Part Status | Active |
| Architecture | SAR |
| Input Voltage | 4.096V |
| Package Width | 7.6(Max) |
| Sampling Rate | 117ksps |
| Converter Type | General Purpose |
| Number of ADCs | 1 |
| Package Height | 2.35(Max) |
| Package Length | 15.6(Max) |
| Sample and Hold | Yes |
| Full Scale Error | ±2.5LSB |
| Supplier Package | SOIC W |
| Input Signal Type | Single-Ended |
| Voltage Reference | Internal|External |
| Single-Ended Input | Yes |
| Standard Package Name | SOP |
| Voltage Supply Source | Single |
| Digital Interface Type | Serial (SPI) |
| Digital Supply Support | No |
| No Missing Codes (bit) | 12 |
| Number of Input Channels | 8 |
| Polarity of Input Voltage | Unipolar |
| Supplier Temperature Grade | Commercial |
| Integral Nonlinearity Error | ±1LSB |
| Maximum Power Dissipation (mW) | 50 |
| Typical Power Dissipation (mW) | 30 |
| Maximum Single Supply Voltage (V) | 5.25 |
| Minimum Single Supply Voltage (V) | 4.75 |
| Typical Single Supply Voltage (V) | 5 |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Description |
