Analog to Digital Converters - ADCs AD7701AN
ADI
AD7701AN
--
Data Acquisition
Analog to Digital Converters - ADCs
Specification
| Product Attribute | Attribute Value |
| HTS | 8542330001 |
| PPAP | No |
| SVHC | Yes |
| EU RoHS | Not Compliant |
| Mounting | Through Hole |
| ECCN (US) | EAR99 |
| Packaging | Tube |
| Pin Count | 20 |
| Automotive | No |
| Input Type | Voltage |
| Lead Shape | Through Hole |
| Resolution | 16bit |
| PCB changed | 20 |
| Part Status | Obsolete |
| Architecture | Delta-Sigma |
| Input Voltage | 2.5V|±2.5V |
| Package Width | 7.24 |
| Sampling Rate | 4ksps |
| Converter Type | General Purpose |
| Number of ADCs | 1 |
| Package Height | 3.43 |
| Package Length | 24.51 |
| Sample and Hold | Yes |
| Full Scale Error | ±2LSB |
| Supplier Package | PDIP |
| Input Signal Type | Single-Ended |
| Voltage Reference | External |
| Single-Ended Input | Yes |
| Standard Package Name | DIP |
| Voltage Supply Source | Dual |
| Digital Interface Type | Serial |
| Digital Supply Support | Yes |
| SVHC Exceeds Threshold | Yes |
| Number of Input Channels | 1 |
| Polarity of Input Voltage | Unipolar|Bipolar |
| Supplier Temperature Grade | Commercial |
| Integral Nonlinearity Error | ±0.003%FSR |
| Maximum Power Dissipation (mW) | 37 |
| Typical Power Dissipation (mW) | 25 |
| Maximum Dual Supply Voltage (V) | ±5.5 |
| Minimum Dual Supply Voltage (V) | ±4.5 |
| Typical Dual Supply Voltage (V) | ±5 |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Description |
