Analog to Digital Converters - ADCs AD7572BQ05
ADI
AD7572BQ05
--
Data Acquisition
Analog to Digital Converters - ADCs
Specification
| Product Attribute | Attribute Value |
| HTS | 8542.39.00.01 |
| PPAP | No |
| SVHC | Yes |
| EU RoHS | Not Compliant |
| Mounting | Through Hole |
| ECCN (US) | EAR99 |
| Packaging | Tube |
| Pin Count | 24 |
| Automotive | No |
| Input Type | Voltage |
| Lead Shape | Through Hole |
| Resolution | 12bit |
| PCB changed | 24 |
| Part Status | NRND |
| Architecture | SAR |
| Input Voltage | 5V |
| Package Width | 7.87(Max) |
| Converter Type | General Purpose |
| Number of ADCs | 1 |
| Package Height | 3.56(Max) |
| Package Length | 32.51(Max) |
| Sample and Hold | No |
| Full Scale Error | ±10LSB |
| Supplier Package | CDIP |
| Input Signal Type | Single-Ended |
| Voltage Reference | Internal |
| Single-Ended Input | Yes |
| Standard Package Name | DIP |
| Voltage Supply Source | Dual |
| Digital Interface Type | Parallel |
| Digital Supply Support | No |
| No Missing Codes (bit) | 12 |
| SVHC Exceeds Threshold | Yes |
| Number of Input Channels | 1 |
| Polarity of Input Voltage | Unipolar |
| Supplier Temperature Grade | Industrial |
| Integral Nonlinearity Error | ±1LSB |
| Maximum Power Dissipation (mW) | 215 |
| Typical Power Dissipation (mW) | 135 |
| Maximum Dual Supply Voltage (V) | -15.75/5.25 |
| Minimum Dual Supply Voltage (V) | -14.25/4.75 |
| Typical Dual Supply Voltage (V) | -15/5 |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -25 |
| Description |
