Analog Switch Multiplexers TS4102ITQ1633T
Silicon Labs
TS4102ITQ1633T
--
Electronic Switches
Analog Switch Multiplexers
Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| Type | Analog Switch|Analog Multiplexer |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| Polarity | Non-Inverting |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Pin Count | 16 |
| Automotive | No |
| PCB changed | 16 |
| Part Status | Obsolete |
| Configuration | Triple 2:1 |
| Package Width | 3 |
| Package Height | 0.8(Max) |
| Package Length | 3 |
| Supplier Package | TQFN EP |
| Input Signal Type | Single |
| Power Supply Type | Single |
| Output Signal Type | Single |
| Chip Enable Signals | Yes |
| Switch Architecture | SPDT |
| Multiplexer Architecture | 2:1 |
| Maximum Turn-On Time (ns) | 9000@5.25V |
| Number of Inputs per Chip | 6 |
| Maximum Turn-Off Time (ns) | 800@5.25V |
| Number of Outputs per Chip | 3 |
| Maximum On Resistance (Ohm) | 105@1.25V |
| Maximum Supply Current (mA) | 0.000765@5.25V |
| Number of Channels per Chip | 3 |
| Typical Supply Current (mA) | 0.000675@5.25V |
| Maximum Power Dissipation (mW) | 1398 |
| Maximum On Resistance Range (Ohm) | 100 to 150 |
| Maximum Single Supply Voltage (V) | 5.25 |
| Minimum Single Supply Voltage (V) | 0.8 |
| Typical Single Supply Voltage (V) | 3|5 |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Description |
