Analog Switch Multiplexers LTC201ACN
ADI
LTC201ACN
--
Electronic Switches
Analog Switch Multiplexers
Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| SVHC | Yes |
| Type | Analog Switch |
| EU RoHS | Not Compliant |
| Mounting | Through Hole |
| Polarity | Non-Inverting |
| ECCN (US) | EAR99 |
| Pin Count | 16 |
| Automotive | No |
| Lead Shape | Through Hole |
| PCB changed | 16 |
| Part Status | Unconfirmed |
| Configuration | Quad SPST |
| Package Width | 6.48 |
| Package Height | 3.3 |
| Package Length | 19.56(Max) |
| Supplier Package | PDIP N |
| Input Signal Type | Single |
| Power Supply Type | Single|Dual |
| Output Signal Type | Single |
| Chip Enable Signals | Yes |
| Switch Architecture | SPST |
| Standard Package Name | DIP |
| SVHC Exceeds Threshold | Yes |
| Maximum Turn-On Time (ns) | 600@5V |
| Number of Inputs per Chip | 4 |
| Maximum Turn-Off Time (ns) | 300@5V |
| Number of Outputs per Chip | 4 |
| Supplier Temperature Grade | Commercial |
| Maximum On Resistance (Ohm) | 525@5V |
| Maximum Supply Current (mA) | 0.02@5V |
| Number of Channels per Chip | 4 |
| Typical Supply Current (mA) | 0.008@5V |
| Maximum Power Dissipation (mW) | 500 |
| Maximum Dual Supply Voltage (V) | ±15 |
| Maximum On Resistance Range (Ohm) | 400 to 1000 |
| Maximum Single Supply Voltage (V) | 44 |
| Minimum Single Supply Voltage (V) | 5 |
| Typical Single Supply Voltage (V) | 9|12|15|18|24|28 |
| Maximum Operating Temperature (°C) | 70 |
| Minimum Operating Temperature (°C) | 0 |
| Maximum High Level Output Current (mA) | 20 |
| Description |
