Analog Switch Multiplexers LT6555IUF
ADI
LT6555IUF
--
Electronic Switches
Analog Switch Multiplexers
Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| SVHC | Yes |
| Type | Analog Multiplexer/Amp |
| EU RoHS | Not Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Pin Count | 24 |
| Automotive | No |
| Lead Shape | No Lead |
| PCB changed | 24 |
| Part Status | Unconfirmed |
| Configuration | Triple 2:1 |
| Package Width | 4 |
| Package Height | 0.75(Max) |
| Package Length | 4 |
| Supplier Package | QFN EP |
| Input Signal Type | Single |
| Power Supply Type | Dual|Single |
| Output Signal Type | Single |
| Chip Enable Signals | Yes |
| Standard Package Name | QFN |
| SVHC Exceeds Threshold | Yes |
| Multiplexer Architecture | 2:1 |
| Number of Inputs per Chip | 6 |
| Number of Outputs per Chip | 3 |
| Number of Channels per Chip | 3 |
| Maximum Dual Supply Voltage (V) | ±6 |
| Minimum Dual Supply Voltage (V) | ±2.25 |
| Typical Dual Supply Voltage (V) | ±5|±3 |
| Maximum Single Supply Voltage (V) | 12 |
| Minimum Single Supply Voltage (V) | 4.5 |
| Typical Single Supply Voltage (V) | 9|5 |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Low Level Output Current (mA) | 70 |
| Maximum High Level Output Current (mA) | 70 |
| Description |
