Analog Switch Multiplexers ADG467BRS
ADI
ADG467BRS
--
Electronic Switches
Analog Switch Multiplexers
Specification
| Product Attribute | Attribute Value |
| HTS | 8542.39.00.01 |
| PPAP | No |
| SVHC | Yes |
| Type | Analog Switch |
| EU RoHS | Not Compliant |
| Mounting | Surface Mount |
| Polarity | Non-Inverting |
| ECCN (US) | EAR99 |
| Packaging | Tube |
| Pin Count | 20 |
| Automotive | No |
| Lead Shape | Gull-wing |
| PCB changed | 20 |
| Part Status | Obsolete |
| Configuration | Octal SPST |
| Package Width | 5.3 |
| Package Height | 1.75 |
| Package Length | 7.2 |
| Supplier Package | SSOP |
| Input Signal Type | Single |
| Power Supply Type | Dual |
| Output Signal Type | Single |
| Chip Enable Signals | Yes |
| Switch Architecture | SPST |
| Standard Package Name | SOP |
| SVHC Exceeds Threshold | Yes |
| Number of Inputs per Chip | 8 |
| Number of Outputs per Chip | 8 |
| Supplier Temperature Grade | Industrial |
| Maximum On Resistance (Ohm) | 95@±15V |
| Maximum Supply Current (mA) | ±0.0005@±15V |
| Number of Channels per Chip | 8 |
| Typical Supply Current (mA) | ±0.00005@±15V |
| Maximum Power Dissipation (mW) | 800(Typ) |
| Maximum Dual Supply Voltage (V) | ±20 |
| Minimum Dual Supply Voltage (V) | ±4.5 |
| Typical Dual Supply Voltage (V) | ±15 |
| Maximum On Resistance Range (Ohm) | 80 to 100 |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Description |
