AC to DC Switching Converters SG3845DM
Microchip Technology
SG3845DM
--
Power Management
AC to DC Switching Converters
Specification
| Product Attribute | Attribute Value |
| HTS | 8542.31.00.01 |
| PPAP | No |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| Topology | Off-Line Switcher |
| ECCN (US) | EAR99 |
| Pin Count | 8 |
| Automotive | No |
| Lead Shape | Gull-wing |
| PCB changed | 8 |
| Part Status | Active |
| Package Width | 3.94(Max) |
| Package Height | 1.75(Max) |
| Package Length | 5(Max) |
| Supplier Package | SOIC |
| Soft Start Option | No |
| Standard Package Name | SO |
| Switching Frequency (kHz) | 500 |
| Maximum Supply Voltage (V) | 30(Typ) |
| Supplier Temperature Grade | Commercial |
| Maximum Output Current (mA) | 200(Typ) |
| Maximum Operating Current (mA) | 17 |
| Maximum Under Voltage Lock Out (V) | 9 |
| Minimum Under Voltage Lock Out (V) | 7.8 |
| Typical Under Voltage Lock Out (V) | 8.4 |
| Maximum Operating Temperature (°C) | 70 |
| Minimum Operating Temperature (°C) | 0 |
| Description |
