Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| Type | Switching Diode |
| EU RoHS | Compliant with Exemption |
| Diameter | 2.67(Max) |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Pin Count | 2 |
| Automotive | No |
| Lead Shape | No Lead |
| PCB changed | 2 |
| Part Status | Active |
| Configuration | Single |
| Package Length | 5.2(Max) |
| Supplier Package | DO-213AB |
| Standard Package Name | SOD-80 |
| Peak Forward Voltage (V) | 1.1 |
| Peak Reverse Current (uA) | 10 |
| Supplier Temperature Grade | Commercial |
| Maximum DC Reverse Voltage (V) | 400 |
| Maximum RMS Reverse Voltage (V) | 280 |
| Maximum Operating Temperature (°C) | 175 |
| Minimum Operating Temperature (°C) | -65 |
| Peak Reverse Repetitive Voltage (V) | 400 |
| Peak Non-Repetitive Surge Current (A) | 30 |
| Maximum Continuous Forward Current (A) | 1 |
| Maximum Junction Ambient Thermal Resistance | 75°C/W |
| Description |
