SBC2-681-211
SBC2-681-211
Inductor Leaded SBC2-681-211
KEMET
SBC2-681-211
--
Magnetics
Inductor Leaded
SBC2-681-211.pdf
Specification
Product AttributeAttribute Value
PPAPNo
TypePower Choke
EU RoHSCompliant
MountingThrough Hole
ECCN (US)EAR99
PackagingBulk
Tolerance10%
AutomotiveNo
Lead StyleRadial
TechnologyWirewound
Part StatusActive
Core MaterialFerrite
Inductance (H)680u
Protection StyleUnshielded
Number of Terminals2
Product Height (mm)10.5
Terminal Pitch (mm)4
Product Diameter (mm)7
Maximum DC Current (A)0.29
Maximum DC Resistance (Ohm)3.1
Inductance Test Frequency (Hz)10K
Maximum Saturation Current (A)0.26
Maximum Operating Temperature (°C)105
Minimum Operating Temperature (°C)-20
Inductance Decrease Percentage @ Isat (%)10
Description
Power Choke Unshielded Wirewound 680uH 10% 10KHz Ferrite 0.29A 3.1Ohm DCR RDL Bulk
