DAC7725NBG4
DAC7725NBG4
Digital to Analog Converters - DACs DAC7725NBG4
Texas Instruments
DAC7725NBG4
--
Data Acquisition
Digital to Analog Converters - DACs
Specification
Product AttributeAttribute Value
PPAPNo
EU RoHSCompliant
MountingSurface Mount
PackagingTube
Pin Count28
AutomotiveNo
Lead ShapeJ-Lead
Resolution12bit
Output TypeVoltage
PCB changed28
Part StatusUnconfirmed
ArchitectureR-2R
Package Width11.58(Max)
Converter TypeGeneral Purpose
Package Height4.57(Max) - 0.51(Min)
Package Length11.58(Max)
Conversion Rate100ksps
Output PolarityUnipolar|Bipolar
Full Scale Error±2LSB
Supplier PackagePLCC
Power Supply TypeSingle|Dual
Voltage ReferenceExternal
Standard Package NameLCC
Digital Interface TypeParallel
Digital Supply SupportYes
Number of DAC Channels4
Maximum Settling Time (us)10
Number of Outputs per Chip4
Integral Nonlinearity Error±1LSB
Maximum Power Dissipation (mW)250
Maximum Dual Supply Voltage (V)±15.75
Minimum Dual Supply Voltage (V)±14.25
Typical Dual Supply Voltage (V)±15
Maximum Single Supply Voltage (V)15.75
Minimum Single Supply Voltage (V)14.25
Typical Single Supply Voltage (V)15
Maximum Operating Temperature (°C)85
Minimum Operating Temperature (°C)-40
Description
DAC 4-CH R-2R 12-bit 28-Pin PLCC Tube
